110V/230V 42W Universal Ultraviolet Light Ballast for Dual 21W Germicidal UV Light
110V/230V 42W Universal Ultraviolet Light Ballast for Dual 21W Germicidal UV Light
Product Parameters for 42w Ultraviolet Light Ballast
Operating Voltage Range | 99-264 |
Max Input Power | 46W |
Max Input Current | 0.2A @ 230V 0.38@120V |
Lamp Power | 1*Lamp: 10-41W; 2*Lamps: 10-21W |
Lamp Current | 0.38-0.43A |
Operating Frequency | 50-70KHZ |
Preheat Time | 1.0-2.0 S |
Preheat Current | 0.4-0.5A |
Power Factor | ≥ 0.98 |
Efficiency | >90% |
Total Harmonic Distortion | <15% |
Crest Factor | <1.7 |
Ambient Humidity | 5%-85% |
Ambient Temperature | -15-40℃ |
Max Case Temperature | 70℃ |
Case Material | Aluminum Shell |
Safety Norm | EN61347-1-2-3, EN62493 |
LVD Norm | Low voltage Directive 2014/35/EU |
EMC Norm | EN55015, EN55014, GB17743, GB17625, EN61000-3-2 |
Certificates | CE/UL/CCC |
Features of the electronic uv lamp ballast
1> Wide input voltage range: 99-264V ac, can be used for different countries with different electricity voltage.
2> With Pre-heat strat function, suitable for frequent start & stop applications. long service life up to 50000 switching cycles.
3> Energy saving, By using electronic circuittry to control the power supply, these ballast minimize erngery wastage consuming 30% less comparing to traditional magnetic ballasts.
4> Stable and efficient disinfection. due to their ability to provide precise control over the uv lamps' output
5> Prolong germicidal uv light lifespan, reduce opertation cost. The precise regulation of power supply helps to extend the lifespan of the
uv lamps, reducing the frequency of replacements and maintenance.
6> This 42W ultraviolet ballast with status indication via 5V DC signal output indicator. DC Output: 5V Lamps on,DC Output: 0V Lamps failure
Compatible uv lights and lamps:
This 120/230V 42W ultraviolet light ballast have two wiring method:
Wiring A 1*lamp operation: GPH793T5 GPH843T5 TUV36T5 TUV25WT5 TUVPL-L36W
Wiring B 2*lamps operation: GPH436T5 GPH357T5 GPH303T5 GPH287T5 GPH212T5
Dimension of this 2*21W Electronic UV Lamp Ballast
Size:165*38*30mm Carton Size: 460*270*190mm(70PCS Load)
Mounting hole spacing: 157mm
Wiring Diagram for this ultraviolet light ballast
Cautions:
1. Please make sure the power is off when you install or maintain the ballast
2. The distance between ballast and lamp tube should no longer than 5M.
3. The suggested wire specific: diameter 0.5-1mm, wire stripping 0.8-1mm
4. The aluminum shell should be grounded.
Applications:
Some Questions About Our Ultroviolet Ballasts You Might Concern.
Q1: What is the Warranty for Your uv lamp electronic ballast ?
A1: Our warranty for Electronic UV Ballast is 12,000 Hours or 2 to 5 years depending on the models.
Q2: Can I get samples before place orders?
A2: Yes, we offer samples for our customers to test before bulk orders, the sample charge will be refunded once you place an order.
that means you are getting a free sample.
Q3: How you ship the order to our Country?
A3: For sample or small orders, express will be best shipping method, such as DHL, TNT, FEDEX.
For bulk orders (more than 100kg), you can choose air freight, sea cargo or by Railway.
Q4: How to pay?
A4: 1. For sample/small orders 100%TT in advance. or by Paypal or Western Union
2. For bulk orders 50%TT in advance and balance paid before shipment (more than USD10000)
Q5: What about the OEM service?
A5: We offer OEM service for our clients, the logo, package design, and stickers all can be customized.
Q6: What is delivery time for the electronic uv lamp ballasts?
A6: For the items we have stock, can be shipped out within 3 days.
For the items dont have stock, can be shipped out within 7 to 15 days after payment.
